gnored ingearing calculations. The next sketch (Fig. 17) showsan arrangement of four wheels in which the gap between A and B is filled with two wheels,both fastened together or keyed on the same shaft. Themethod is used extensively in textile machinery. The arrows indicate the directions of… … Fi<|. 16. 10 TEXTILE MECHANICS wheel drives B, and except when the two wheels C and Dare equal in teeth, any difference in their sizes will make adifference in the speed of B. Whilst C and D are thereforecarriers, they must be distinguished from single carriers, andthis distinction is usually…
