An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 276
)osite direction from that indicated by the arrowand the belt is sliifted onto the loose pulley. This movement does notdisconnect the train of gears, between the reverse shaft and cone rackas the stop-motion latch is not moved. Full Bobbin Stop Motion. When the bobbin has reached its fulldiameter,… … Fig. 173. Tension Gearing. wait for this stop motion to operate before doffing, it acts as a safe-guard, for, if the frame is allowed to run too long, there is danger ofthe builder jaws coming together, which often results in stripping thebuilder screw. There is also some difficulty in doffing, if…

Textile fabrics · Textile industry
