Taggart, William Scott · London : George Routledge & Sons, Ltd. · leaf 36
ere it forms part of the gearing of a self-acting mule.The double clutch box or the reversing clutch box is indicatedat W and X. A single clutch box is shown at Y, and at Uis the cone clutch of the backing-off on the rim-shaft. Itis not necessary at this point to explain this apparent com- TEXTILE… … so that we can obtain forward motion, backward motion, inter-mittent motion, or no motion at certain desired points. Studentswill find the example a good study in tracing out speeds anddirections on the supposition of the clutches being in or out ofaction. EXERCISES 1. A line-shaft runs at 320…
Textile machinery
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
