Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 361

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 361
Fig. 234. Elevation Showing Carriage Shaft Clutch. up friction, P, engages with the lower part, T^,and the carriage is drawn in. The scrolls, Aand B, serve for this purpose, while the scroll,C, acts as a check upon the carriage. Thescroll band unwinds from C while the otherbands are winding around…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
