Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 81

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 81
ELEIVATIONOF PIPI NO … Fig. 24. Plan and Sectional Elevation of Feeders in Storehouse. A and B, with especially large hoppers, which are driven by anelectric motor and which deliver the cotton to the conveying pipe,C, through mouthpieces, D. The fan, E, for drawing the cottonthrough the pipe, is placed in the opener room…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
