Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 95

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 95
is a roll, or drum, Q, which is connected -to the main saddle bya thin steel band, S, and a }oke, U. One end of the band passes ^5 \ 50 COTTON SPINNING. partially around the drum and the other is fastened to the lowerend of the yoke. On the other end of the shaft is a quadrant,W, which is connected…

Textile fabrics · Textile industry
