Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools (1901)

Zipser, Julius, Salter, Charles · London : Scott, Greenwood · leaf 316

An illustration from Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools, 1901, leaf 316 — e upper end with acone, h, made of compressed sheets of paper, and driven bythe conical cast-iron pulley, i, mounted on the transversedriving shaft, /, and driven by the belt pulle\, k, or by thecranks, ii, and speed multiplying gear, 0, p. The centrifugal force arising from the rapid rotation of… … or the hand cranks have been released. The whole machineis firmly bolted on to the foundation by screw-bolts, t. 3IO TEXTILE RAW MATERIALS. The newer form of hydro-extractor is illustrated by thevertical section given in Fig. 192, wherein the correspondingparts are lettered the same as Figs. 190…

Textile fibers · Spinning

Internet Archive Book Images · Claire T. Carney Library, University of Massachusetts Dartmouth · No known copyright restrictions (public domain). Free to use for anything.
