Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School of Correspondence · Chicago, American School of Correspondence · leaf 105
lap is governed by the num-ber of yards it contains and is measured by the revolutions of thelap roll, the picker being stopped automatically after the requirednumber of yards has been wound. The device, by which this isregulated, is called the knock-off, a diagram of the gearing ofwhich is shown… … Fiff. 45. Diagram of Knock-oft Gearing. W, driven by a pin, V, whicli forms jjart of the gear. As the lat-ter turns, the dog is brought against the upper end of the knock-off latch, E, moving it out and allowing the drop lever, M, to fall,disengagmg the pinion, S, and the gear, R, and, as the dog…
Textile fabrics · Textile industry
