Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 141

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 141
. 70 and 71, is called the scrolladjustment. The bend, D, is supported at three points by arms,A, B and C, instead of five, as in the first one shown, the bend COTTON SPINNING. fi7 being made proportionately heavier and stifEer. The arms, A andC, are connected to the bend by a stud, F, which passes… … in the ai-m, prevents any circumferential movement of the bend.Tlie arms are all made in two pieces, partly for convenience inmanufacturing and in order to set them alike when the card isfirst erected. Adjusting screws, L, are provided for the two end. COTTON SPINNING. ones, which, afte: being- set…
