Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 206

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 206
needles, it is evident that the end, held betweenthe nipper and cushion plate, can receive, no combing but as theyare liberated by the opening of the nipper and are carried forward 146 COTTON SPIXNING. for pieci-ng-up, the top comb, H^, descends into the path of thecotton and it receives combing by… … Fig. 125. Elevation SLiowing Detacliiug Roll Cams. Detaching Roll Cams. To obtain the various movements ofthe detaching rolls, three cams are employed; those which impartrotary motion to all of the rolls are shown in Figs. 125 to 130 in-clusive and the lifting cam which causes the rolls, F and G,…

Textile fabrics · Textile industry

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
