Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 236

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 236
between two rolls connected with opposite poles of an elec-tric generator, prevent the flow of the electric current. As long.as the sliver is between these rolls, the stop motion remains in-operative, but should it break and allow the rolls to come together,the circuit is completed and the machine… … Fig. 145. Magnet Box tor Electric Back Stop Motion. ducted by means of rods, or wires, from the generator, which isconveniently located and is usually furnished for a certain numberof deliveries of drawing. The positive pole or wire. A, is indicated by the sign -)- andthe negative wire, Z^ by the…

Textile fabrics · Textile industry
