ing the magnet M of a secondary clock. Thisattracts its armature b, operates the pawl which moves forwardand catches one of the teeth of the wdieel e. As soon as thecontact is broken at c a spring acting upon the armature h drawsit away from the magnet, and at the same time the pawl moves the■wheel… … 296 HOROLOGICAL.
