Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 274

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 274
. Elevation Showing ReverseCrank and Gearing. 206 COTTON SPINNING is moved in the opposite (llrection from that indicated by the arrowand the belt is siiifted onto the loose pulley. This movement does notdisconnect the train of gears, between the reverse shaft and cone rackas the stop-motion latch… … Fig. l.?. Tension Gearing. wait for this stop motion to operate before dofBng, It acts as a safe-guard, for, if the frame is allowed to run too long, there is danger, ofthe builder jaws coming together, which often results in stripping thebuilder screw. There is also some difficulty in doffing, if…

Textile fabrics · Textile industry
