fromthe shaft, Y^. The weight of the cone hangs upon the cone belt, D^,and keeps it tight. The connection, from the bottom cone to the gearing, is throughthe cone gear, C^, which has twenty-two teeth. This gear is some-times changed when the diameter of the empty bobbin is so small thatthe… … COTTON SPINNING 209 the bobbins to run at a greater speed. The cone belt is then shiftedalong the cones until the position of tlie belt is such tliat the rovingtakes up or winds correctly. The taper gear, F^ has from ele-.en to foiu-teen teeth. This is adriven gear and the fewer teeth it has, the…
