the shaft, Y^. The weight of the cone hangs upon the cone belt, D^,and keeps it tight. The connection, from the bottom cone to the gearing, is throughthe cone gear, C^, which has twenty-two teeth. This gear is some-times changed when the diameter of the empty bobbin is so small thatthe difference… … « .3 o 5 fa o w w 5 s = fa -3 5 w COTTON SPINNING 209 the bobbins to run at a greater speed. Ilie cone belt is tlien shiftedalong the cones until the position of the belt is such that the rovingtakes up or winds correctly. The taper gear, F*, has from eleven to fourteen teeth. This is adriven gear…
