Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 305

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 305
finally upon the bobbin, O. 274 COTTON SPINNING 233 The drum, F, extends the whole length of the frame, and uponone end of it are the driving pulleys. The spindles are driven fromthe drum by the bands, B, one for each spindle. The ring rails are fastened to the top of the lifting rod, bywhich they… … Pig. 194. Elevation Showing Roll Stand and Weighting. for each spindle and the creel is one story, usually. For doubleroving, there are two bobbins or ends for each spindle and the creelis two storied. A plan of a creel for a two and three-cjuarter inch spaced ringframe, for double roving with…

Textile fabrics · Textile industry
