s an enlargedpart of the pipe, rectangular in section and in which is a gate, K, 3.6 COTTON SPINNING. shown by dotted .lines, which may be operated from tlie outside ofthe pipe. From this point, tlie pipe divides, line, F, leading to con-denser, G, and line, H, to condenser, J. If it is desired to… … *W^ Fig. 25. Plans and Sectional Elevation, showing details of piping forBlowing System. the gate is moved straightway of the pipe, leaving both branchpipes open to the condensers. The dust and dirt from the condensers are discharged into thedust room tlirough the pipe, L, by the fan, M. Wlien only…
