An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 87
Fig. 30. Elevation Showing Evener Parts. towards the elevating apron. When the hopper is full, or nearly so,the cotton keeps the rack in an almost vertical position, but as it COTTON SPINNING. 41 … COTTOX SPIXXIXG. gets low in tliu hopper, tlie springs draw the rack forward towardsthe elevating apron while the comb is drawn slightly away fromit. By thus increasing the distance between the comb and theapron (which is sho-wii by the dotted lines in Fig. 29), morecotton is allowed to pass…
