fallers are more visible, and may be removed mucheasier. As an example of the method of finding the draft of a gill box,the draft will be calculated from the plan and side elevation shown inFig. 90. The diameter of the l)ottom front and back rolls (which arethe drivers) is three and one-half… … Z 6 < o WOOLiEN AND WORSTED SPINNINC 139 bevel gears BB of 22 teeth. These bevel gears mesh with the bevelgears CC on the screw shaft, which also have 22 teeth. DD are thetop screws; E is the bottom back roll; F is the bottom front roll; andGG are the calender rolls, which take up the sliver as…
