e kept from rising by the friction of the break lever againstthe break pulley. When it has been wound to its full diameter,the attendant presses down upon the break lever, releasing it fromcontact with the break pulley; then the rack can be raised byturning the handwheel, J, on the end of the rack… … QZ P 3 H ^ 2: 6 Z 2 > ^ o a oo ^ W bn Z ^ 0 0 u ^ K m U Z =y M ^_^ > j;^ M ci W H h-i COTTON SPINNING. 55 while the pinion, W, which gears into the rack, K, is connected tothe rack shaft by a lug projecting between the arms of a dog, orcarrier, T, which is keyed to the rack shaft. In the arms…
