Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 272

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 272
uarter of a revolution, from C to D. The lengthof the yarn wound will be equal to the distance around the barrel … Fig. 136. Diagram Sliowing Difference in Speeds of Flyer and Bobbin. of the bobbin from D to E which is one-<:|uarter of its circumfer-ence or about .78 of an inch. Diagram number 2 shows the bobbin as two inches in diam-eter. The flyer has made one-half of a revolution from A to B,the same as…

Textile industry · Textile fabrics
