theother. When connected to the external circuit by means of col-lector rings, this alternating E. M. F. is impressed directlyon the external circuit; but by using a suitably arrangedcommutator, the connections between the coils of the arma-ture winding and the external circuit may be reversed… … ductors, a b c, is wound on a ring core and connected to thetwo commutator segments S and S, each of which coversnearly one-half the circumference of the commutator. On APPLIED ELECTRICITY. 1939 these two segments rest the two brushes -}-B and —B, theybeing placed opposite each other and making…
