Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 313

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 313
Details of Builder Shoe and Rail. as the carriage runs out it will come in contact with lever Q^^ causingthe sickle-shaped pair to drop, thus raising the other end and chainattached to it, which in turn raises the lever arm Q. (Fig, 169.)This lever is pivoted, one end supporting a pawl which meshes…

Textile industry · Textile fabrics
