LAP ROLU12 DIA. Fig. 109. Diagram of Gearing ofSliver Lap Machine. The fulcrum for the weight lever is a projecting lug. Si, upon theframe of the machine. Calculations. Fig. 109 is a diagram of the gearing of thesliver lap machine. Rule 1. To find the draft: Multiply the number of slivers,entering… … COTTON SPINNING. 131 (42.5) unci divide the product by the weiglit of the lap ingrainsper yard (272). „ . 42.5X16 -.li<xampie : —^^^^ =^ 2.o This will require a draft gear of 55 teeth which is shown onthe plan of the gearing. Rule 2. To find the production of the machine: Multiplytogether the…
