ed with flannel andsupported at either end by arms, W^. As the flats pass aroundthe front block, the strippings, which are removed by the comb, 111 COTTON SPINNING. are wound upon the roll which revolves by being held lightly, incontact with the flats. It was the custom, formerly, to allow the… … mmm Fig. 68. Section of cylinder and doffer. quickly, and by reason of the compactness, the removal does nothave to be performed so often. When it is necessary to grind, or strip, the cylinder, the door,W, which is hinged to the front plate, can be turned down asshown by dotted lines. Over the…
