A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 153

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 153
f ref-erence accompanying theillustrations, and of which1 represents part of theloom frame, 2 part of thelay, which carries a pin 3,engaging with a slottedlever 4, hung to a pin 5,which is adjustable longi-tudinally in a slotted lug 6fast to frame 1. Lever 4has a slot 7, which engagesthe pin 3, and… … secured to and projecting from a slide 13 on the sideframe 1 of the loom. Vertical adjustment of this 153 slide 13 on the loom frame is effected by providingsaid frame with a vertical slot 14 for the reception

Textile fabrics · Textile industry · Textile machinery

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
