American School of Correspondence · Chicago, American school of correspondence · leaf 138
Fig. 66 and 67. Elevations of calendar, roll stop motion. The stop-motion is shown in three views, in Figs. 66, 67 and68, which should be used in connection with Fig. 60. In Fig. 66,which is a side elevation, the sliver, A, is shown passing betweenthe calender rolls, ]\I and D. Updn the top…
Textile industry and fabrics
