Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 203
slow motion. The gears are timedto impart their greatest speed during the change from one box toanother, which regulates the color of filling to enter the cloth.While it is not only advisable but liecessary to have the boxeschanged in time, it is not always desirable to have too rapid action, 175… … cq O &C s 1, is fixed on the picking cam shaft and geared into 2, each having27 teeth. Compounded with 2 is a 22-tooth gear and a segmentgear 3, which has 15 teeth. The 22-tooth gear is the firstof a tram of four gears of the same number of teeth, which transmit 176 WEAVING 163 motion to the…
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
