d the pawl, 01-, out of the notch in the notched wheel,marked by the numeral, II. Fig. 128 shows the cams as having made about one-half ofa revolution. This movement has advanced the cam roll from Ato B and has caused the pawl to move fiom above notch II to IIIwhile the gradually decreasing…
Textile industry and fabrics
