there are six cans at the back, and the sliver from these cans isdrawn through as one sliver, or doubled six into one, the machineis given a draft of six, so that the w^eight of the sliver being de-livered is the same as the weight of that from each can. While 309 170 COTTON SPINNING this is the… … Fig. 143. Front Elevation of Drawing Frame Driven from Above. sliver plate, J, through the trumpet, IST, and between the calenderrolls, E and F. From this point, it falls through the spout of thecoiler, G, and is coiled in the can, li. Stop Motions. The drawing frame is provided with four…
