ws, eachcrank pin being arranged to take the big end bearings of twoconnecting rods from cylinders on opposite sides of the crankcase. There is a bearing between each throw, and in order toreduce the overall length of the engine the cylinders are stag-gered on the crank case. The H section… … Fig. 24. Valves and Valve Motion of A. B. C. Motor. {Aero, London.) the cylinders are staggered, and there is no overhanging ofthe big end bearings at the point of attachment to the con-necting rod. The bearings themselves are lined with whitemetal. The small end bearings are provided with…
