the second floor of the same mill, andFig. 3 is a sectional elevation. The machines on the first floor are an automatic feeder. A,connected to an opener, B; and on the second.floor are a singlebeater breaker picker, D, with a condenser and gauge-box, a singlebeater intermediate picker, E, and a… … dust, dirt and fine particles of cotton are discharged from thepicker by fans, through the galvanized iron pipes, H. Thesepipes are provided with an automatic closing damper, K, wliich is 42
