Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School of Correspondence · Chicago, American School of Correspondence · leaf 48

An illustration from Cyclopedia of textile work; a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 48
the second floor of the same mill, andFig. 3 is a sectional elevation. The machines on tlie fiist floor are an automatic feeder, A,connected to an opener, B: and on the second floor are a singlebeater breaker picker, D, with a condenser and gauge-box, a singlebeater intermediate picker, E, and a… … dust, dirt and fine particles of cotton are discharged from thepicker by fans, through the galvanized iron pipes, H. Thesepipes are provided with an automatic closing damper, K, wliieh is

Textile fabrics · Textile industry

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
