Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 168

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 168
flats pass along to the grindingformer, they are supported upon the projecting arras, E, of thebracket, but as they come directly under the grinding roll, theyare raised slightly by the rounding end of the weight lever, and,by means of the weight, are held firmly against the former. Grinding… … Fig. 95. Section Showing Flat Grinder.

Textile industry · Textile fabrics
