Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 64

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 64
dirt from thecotton. If the drauy-ht is not strong enough the cotton will be 52 COTTON SPINNING. 17 driven dowii through the grid witli the dirt, making too muchwaste, while if it is too strong, the dirt will be drawn along withthe cotton into the lap. The beater grid consists of stationary bars,… … Fig. 8. Section of Breaker Ticker, with Condenser and Gauge Box Section. the last bar is set about 1| inches away. The grid bars are sup-ported by brackets, which arc adjustable, and are bolted to theframe. The space between the bars is graduated, those nearestthe feed roll having the widest space…

Textile industry · Textile fabrics
