Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 242
Fig. 120.Flyer and Bobbin. WOOLEN AND WORSTED SPINNING 191 mangle wheel operates the builder plate at the same speed all thetime the bobbin is being filled. The spindles also are revolving atthe same speed, therefore, it is evident that the empty barrel of thebobbin must take up as much length of… … Fig. 131. Four-Spindle Drawing Box. in speed as it increases in diameter, in order to keep up with the flyer.On a cone drawing box the bobbin is carried around by the bob-bin gear, but in open drawing the bobbin is loose on the spindle,and the drag is regulated by cloth or leather washers placed…
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
