Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 251

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 251
y gearsto the cone, any slight variation of the cone affects the crown gear.The driving gear C and the crown gear impart their speed to the bob-bin gear. Its speed will be in excess of the spindle gear S. As an illustration of its influence, we will suppose the drivingshaft is making 300… … •18 1V60LEN AND WORSTED SPINNING 199 there are then 310 revolutions or a reduction of thirty caused by theaction of the cones. In Fig. 126, on the shaft O, there is a small bevel pinion M whichgears into N which is fixed on the top of a vertical shaft, at the oppositeend of wliich is another pinion…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
