Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 288

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 288
l bobbin, and E the empty bobbin. The yarn is represented as passingthrough the traveler by the line Y. Withthe full bobbin (Diagram B) the pull ofthe yarn is nearly parallel with the ringand the traveler is rotated with com-parative ease, but with the empty bob-bin (Dagram A) the pull of the yarn… … Fig. 147. Plan of Clamp for Fastening Ringin King Rail.

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
