Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 308

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 308
be wound from the drum M^ causing the spindlesto revolve the greatest number of times. This is due to the fact thatthe length of chain unwound will be nearly equal to the stretch; i. e.,seventy-two inches. If pulley M^ were wound to the top of the screw, it will be readilyseen that less chain will… … 271 250 WOOLEN AND WORSTED SPINNING Mjn ,of the spindles. This shows how the number of revohitions may be varied. The method of turning the screw, thereby raising IVP, is. as fojlows: Attached to the bottom of M^ (see Fig. 163) is a bevel gear wliich meshes with another bevel gear attached to gear…

Textile fabrics · Textile industry
