dog S^ to drop backinto place in the slide S*, so that a roll on gear S^, which is drivenfrom the gear S^ on the drawing-in shaft, may force the drawing-outslide and latch rod back into place. This allows the latch rod tocatch on the casting S^, holding both the slide and rod in position. The… … M 2 O Ho WOOLEN AND WORSTED SPINNING 261 to be drawn in. The drawing-in clutch is thrown out of gear by thecarriage striking against the lever Y (Fig. 161), which releases thebacking-off lever S^% allowing the spring S^ to draw it to a neutralposition. During the running in of the carriage, the…
