Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 232

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 232
TEXTILE DESIGN 189 on which one pick of the design is cut, just as one pick of anordinary design is placed on one bar of the harness chain. Thiscard passes over the cylinder, shown in Fig. 276, in much the samemanner as a bar in the ordinary harness chain passes over the chainbarrel. The cylinder… … y Fig. 274 tact with the ends of the needles B; the ends of the needles enteringthe holes in the cylinder. Now, if a blank card is placed on thecylinder, the holes will be covered and all the needles will bepressed back, carrying their upright hooks out of the path of the 203 190 TEXTILE DESIGN…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
