tl tr 13x46 = (38_4x46 = l64_4!<46 = l84 Fig. 47. Drawing Draft for 11 Harnesses. 54 ends in a pattern. 46 patterns,required on each shaft. 54 X 46 = 2,484 ends. Heddles Harness ISTo 11 —138 heddles, 10 — 184 9—184 8 — 184 7 — 184 6 — 184 5—184 4 — 184 3—92 2 — 506 1 1—460 \ > add a few extra… … Fig. 48. Modern Interchangeable Plain Loom. THE PLAIN POWER LOOM. There are many kinds of plain power looms on the market, butat the present time the demand for such a diversity of cloth neces-sitates so much changing in mills that a loom should be bought inwhich is taken into consideration, this…
