Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 130

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 130
Fig. 63. Diagram for % Dwell. … Fig. 64. Diagram for % Dwell. 100 100 WEAVING. To give the correct shed, the larger cam controls the treadle for theback harness, and the cam with the largest depression is placed overthe front-harness treadle. The front liarness is also connected withthe smallest set collar on the harness roller.…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
