Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 136
inchesstroke. It requires a considerable amount of skill in the setting ofthese motions, but when they are set they give fair results. Yetthe time spent in setting is not balanced by these results. Whencompared with the motion in Fig. 68, it is seen that one is placedinside of the loom and out of… … fa ft WEAVING. 105 The cams for the roll top motion are fixed on an auxiliary shaftand the shaft receives motion from the pick cam shaft. The samerule applies when calculating the gears that drive the cams, except
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
