y depress the extremity, which comes in contact withthe pawls sooner, and thereby shut the valves earlier; and onthe contrary, when the balls are depressed, the valves remainopen longer; as the pawls come in contact with the stemsalways at one point, the steam valves open constantly, but areclosed… … <Pqr 358 WOODKTTFF & BEACHS STEAM EXGINE. Fig. 71 represents, partly in section and partly in plan, thecylinder, steam chests, valves, &c, of one of the Woodruff &Beach high pressure Engines, Wrights patent. Fig. 72 represents, in elevation, the cam shaft, to the upperend of which,…
