Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)
American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 224
ese projections areof such form as to fill the spaces m the small segment gear, and 194 WEAVING 181 act the part of a broad tooth, meshmg with the spaces in the largesegment gear. One side of the slide is twice as long as the other, and conse-quently when one projection is filling a space on the… … Fig. 118. Cromptoii Gingham Loom. to one of the small levers in the upper motion under which therisers in the chain pass. The flat portion of the projection, whenin the small segment gear, almost touches the teeth of the largesegment gear, so that the projection catches when the smallsegment gear…
Textile fabrics · Textile industry
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
