Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)

Chicago : American school of correspondence · leaf 169

An illustration from Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1907, leaf 169
m shedwould be above the back of raceplate, and yet on the frontedgfe. D shows the shuttle away from the reed. If the yarn for the lower shed C, weredropped any lower, it would rest heavily on the front edge andwould be chafed almost continually while weaving. A remedyfor this, is the packing… … Fig. 91. Lay Forward ofPerpendicular. 147 134 WEAVING. The Lay. The following parts comprise the lay: Fig. 92,AA, lay sole, a long piece of wood varying in size, according to T=j0 TJ
