aced one abovethe otlier. The bays of the creel are fixed or changeable ; this beingdetermined by the amount of floor space available. If tlie floorspace is small, changeable bays are used, and the angles of the 19 12 WARP PREPARATION. tiers, or rows of spools, can be changed to suit the altered… … Expansion Reed. J^iom the creel the yarn passes throughan expansion reed. The purpose of this reed is to \ary tlie widthof the ends from the creel so that it will conform to the width of^he beam on which it is to be placed. zo WARP PREPARATION. 13 Heasuring Roll. From the reed the ends pass over…
