Fig. 38.) quicker than with the jacketed vat, thus effecting a considerablesaving; and that the size vat can be more readily cleansed. SeeFig. 28. Immersion Roller. The j^arn j)asses under an immersionroller, which is made of copper and arranged so that it can beraised or lowered, according to the… … Q .2?o Q HO S ■z o WARP PREPARATION. 35 Squeeze Rolls, The yarn on leaving the size box passesthrough two sets of squeeze rolls. There are some instanceswhere only one set of rolls is used, but this method does not givegood results, even with fine yarn, while with coarse yarn theresults are very…
