I^, and a coil spring Y^ isattached to trip Y\ tending to hold it in contact with I^ The shifterfork and handle are fastened to shaft I^ in such a position that thenormal action of the coil spring Y^ is to hold the belt on the loosepulley, but by raising the handle the belt fork shifts the belt… … Fig. 50. Bobbin Rack. 121 108 KNITTING when spring Y returns the belt fork and shifts the beU to the loosepulley. Hole and Bunch Detector. Fastened on top of the cam ring,directly over the end- of trip Y (Fig. 51), is the needle protectorbracket Y^ provided with latch Y^ and finger Y\ Through the…
